Description
The VOX-200 is undeniably the most cost-effective telephone paging amplifier in its category. It has all the required features for basic installations such as the night ringer. It is the perfect solution for low cost/high reliability installations.
Features:
- Built-In Night Ringer
- Music Input (RCA or Screw Terminal)
- 200W RMS Continuous
- 70V Output
- VOX with sensitivity Level Control
- Volume, Bass & Treble level controls
- Separate level controls for Music & Telephone
- Peak Level Indicator
- Output fully short circuit protected
- Thermal and electronic overload protection
- Wall Mount & Rack Mount installation
- Heavy Duty Design
- Made in Canada
- 5 Years Warranty
- UL/CSA Listed
Specs:
| Power Output: | 200 watt RMS Continuous |
| Distortion: | Less than 1% |
| Frequency Response: | ±3 dB, 100 ≈ 20,000Hz |
| Inputs: | TEL: 600Ω balanced line, transformer-isolated MUSIC: 10kΩ unbalanced, Hi-Z source, RCA jacks or screw terminals MUSIC MUTE: Mutes music when shorted CONTACT RING: Triggers night ringer when shorted TEL RING: Triggers night ringer in response to 90V ring signal |
| Indicators & Controls: | POWER, PEAK LEVEL AND FAULT LED indicators. MUSIC VOLUME, MUSIC BASS, MUSIC TREBLE, TEL VOLUME, TEL BASS, TEL TREBLE, VOX, NIGHT RINGER. |
| Outputs: | OUTPUT (70V RMS) |
| Overload Protection: | Thermal and electronic protection with a 4A, 120V ~ slow blow fuse |
| Power Source: | 120V AC, 60Hz |
| Power Consumption: | 420 watts |
| Finish: | Black powder paint with silver and red lettering |
| Dimensions: | 14-¼” W x 8-3/8” H x 2-3/4” D |
| Weight: | 15 lbs |
| Environment: | Indoor |
Specifications subject to change without notice.
